| Nominal Voltage |
12 V |
| Nominal Capacity |
20 Hour Rate |
10.50V 12.00Ah |
| 10 Hour Rate |
10.50V 11.30Ah |
| 5 Hour Rate |
10.20V 11.00Ah |
| 1 Hour Rate |
9.60V 7.20Ah |
| Capacity Affected by Temperature |
30 ℃ ( 86 ℉ ) |
105% |
| 25 ℃ ( 77 ℉ ) |
102% |
| 10 ℃ ( 50 ℉ ) |
94% |
| -10 ℃ ( 14 ℉ ) |
78% |
| Internal Resistance |
25 ℃ Full Charge |
Less Than 16 mΩ |
| Max. Discharge Current |
Continuous |
48 A |
| Constant Voltage Charge |
Stand by Use |
Charging Voltage |
| 13.5 ~ 13.8 V ( 25℃ ) |
| Cycle Use |
Charging Voltage |
| 14.4 ~ 15.0 V ( 25℃ ) |
| Less Than A |
| Battery Container & Cover Material |
ABS |
| Dimension (mm ) |
L-W-H-TH |
151-96-95-99 |
| Weight |
APPROX |
3.6 Kg |
| Terminal Type |
Lead Alloyd |
B Type |
| Life for Stand by Use |
AT 25 ℃ ( 77 ℉ ) |
4 ~ 6 Years |
| Life for Cycle Use |
100 % Discharge |
260 Cycle |
| 50 % Discharge |
600 Cycle |
| 30 % Discharge |
1200 Cycle |
|
