| Nominal Voltage |
12 V |
| Nominal Capacity |
10 Hour Rate |
10.50V 30.00Ah |
| 5 Hour Rate |
10.20V 25.50Ah |
| 3 Hour Rate |
10.20V 23.10Ah |
| 1 Hour Rate |
9.60V 18.60Ah |
| Capacity Affected by Temperature |
30 ℃ ( 86 ℉ ) |
105% |
| 25 ℃ ( 77 ℉ ) |
102% |
| 10 ℃ ( 50 ℉ ) |
94% |
| -10 ℃ ( 14 ℉ ) |
78% |
| Internal Resistance |
25 ℃ Full Charge |
Less Than 11.0 mΩ |
| Max. Discharge Current |
Continuous |
75.0 A |
| Constant Voltage Charge |
Stand by Use |
Charging Voltage |
| 13.50 ~ 13.80 V ( 25℃ ) |
| Cycle Use |
Charging Voltage |
| 14.4 ~ 15.0 V ( 25℃ ) |
| Less Than 7.5 A |
| Battery Container & Cover Material |
ABS |
| Dimension (mm ) |
L-W-H-TH |
196-131-153-168 |
| Weight |
APPROX |
11 Kg |
| Terminal Type |
Lead Alloyd |
E Type |
| Life for Stand by Use |
AT 25 ℃ ( 77 ℉ ) |
5 Years |
| Life for Cycle Use |
100 % Discharge |
260 Cycle |
| 50 % Discharge |
450 Cycle |
| 30 % Discharge |
1200 Cycle |
|
